Kubernetes Scheduling Policies

Kubernetes removed the legacy scheduling policy mechanism in version v1.23. Prior to that release, operators could customize pod placement with --policy-config-file or --policy-configmap flags. The new Scheduler Configuration API replaces those flags and delivers more flexibility and safety.

For details on the new Scheduler Configuration API, see Understanding the Kubernetes Scheduler.

TL;DR

• Legacy scheduling policies used predicates and priorities to filter and score nodes.
• Kube-scheduler flags policy-config-file, policy-configmap, policy-configmap-namespace and use-legacy-policy-config deprecated in v1.23.
• Users must switch to Scheduler Configuration via ComponentConfig API instead of policy files.
• Policy file syntax: kind Policy, apiVersion v1, lists of predicates and priorities in JSON or YAML.
• Migration requires mapping legacy policy sections into Scheduler Configuration plugins and plugin configs.
• Custom flows still support event-driven scheduling via preFilter, filter, score, reserve, permit, preBind, bind plugin points.

Scheduling Policies Overview

Scheduling policies provided a way to tune scheduling decisions in Kubernetes releases before v1.23. Administrators could define which nodes qualified to run a pod (predicates) and assign weights to node scores (priorities). The kube-scheduler binary accepted a policy file or a ConfigMap containing the JSON or YAML policy object.

Legacy Scheduling Policies in Kubernetes <1.23

Legacy policies followed this lifecycle:

• Define a Policy object in JSON or YAML.
• Pass --policy-config-file=/path/to/policy.json or --policy-configmap= at kube-scheduler startup.
• Scheduler read the policy, loaded predicates and priorities in memory.
• Pods triggered the predicate phase, then the priority phase for scoring.
• Scheduler picked the highest-scoring node and bound the pod.

{
  "kind": "Policy",
  "apiVersion": "v1",
  "predicates": [
    {"name": "PodFitsHostPorts"},
    {"name": "PodFitsResources"}
  ],
  "priorities": [
    {"name": "LeastRequestedPriority", "weight": 1},
    {"name": "SelectorSpreadPriority", "weight": 2}
  ]
}

Alternate YAML format:

kind: Policy
apiVersion: v1
predicates:
  - name: PodFitsHostPorts
  - name: PodFitsResources
priorities:
  - name: LeastRequestedPriority
    weight: 1
  - name: SelectorSpreadPriority
    weight: 2

Scheduling Policies: Predicates and Priorities

Predicates execute boolean checks. They exclude nodes that can’t host the pod. Common predicates:

• PodFitsResources – checks CPU and memory requests.
• PodFitsHostPorts – ensures port availability.
• MatchNodeSelector – matches node labels to pod NodeSelector.

Priorities assign node scores. Higher weight increases influence on final sort. Examples:

• LeastRequestedPriority – favors nodes with more free resources.
• BalancedResourceAllocation – balances CPU and memory usage.
• NodePreferAvoidPodsPriority – avoids nodes marked for eviction.

Configuring Scheduling Policies via policy-config-file

To apply a local policy file:

kube-scheduler \
  --policy-config-file=/etc/kubernetes/scheduler-policy.yaml \
  --use-legacy-policy-config

The flag --use-legacy-policy-config ensured compatibility with older code paths. Operators could also tune --policy-configmap-namespace.

Scheduling Policies: ConfigMap-based Approach

ConfigMap mode allowed dynamic updates. Steps:

1. Create a ConfigMap in kube-system namespace:

apiVersion: v1
kind: ConfigMap
metadata:
  name: scheduler-policy
  namespace: kube-system
data:
  policy.json: |
    {"kind":"Policy","apiVersion":"v1","predicates":[],"priorities":[]}

2. Launch kube-scheduler with --policy-configmap flag:

kube-scheduler \
  --policy-configmap=scheduler-policy \
  --policy-configmap-namespace=kube-system

Limitations and Deprecation of Scheduling Policies

Kubernetes deprecated legacy scheduling policy flags in v1.23. The scheduler team removed:
--policy-config-file, --policy-configmap, --policy-configmap-namespace, --use-legacy-policy-config.

Reasons for deprecation:

• Lack of schema validation for policy files.
• Complexity of JSON-based plugin selection.
• Inability to reload policy without restart.

Migrating Scheduling Policies to Scheduler Configuration

The replacement uses the ComponentConfig API. You supply a static YAML file with apiVersion kubescheduler.config.k8s.io/v1beta2. It defines plugin chains for each scheduling stage.

apiVersion: kubescheduler.config.k8s.io/v1beta2
kind: KubeSchedulerConfiguration
profiles:
- schedulerName: default-scheduler
  pluginConfig:
  - name: PodTopologySpread
    args:
      defaultConstraints:
      - maxSkew: 1
        topologyKey: zone
  plugins:
    filter:
      enabled:
      - name: PodFitsResources
    score:
      enabled:
      - name: LeastAllocated
        weight: 1

Scheduler Configuration vs Scheduling Policies

The new model treats predicates and priorities as filter and score plugins. ComponentConfig enforces schema validation at startup. It supports dynamic plugin loading in future versions. You can group multiple profiles to support multi-scheduler setups.

Use Cases for Custom Scheduling Policies

Operators may still require custom logic:

• Enforce zone-aware placement for HA workloads.
• Isolate batch jobs on specific node pools.
• Implement priority inheritance across namespaces.

Custom plugins integrate with the scheduler framework. Build a Go module that implements the Filter or Score interface, compile as a plugin, then reference it in the scheduler config.

Workflow Diagram
